iZ Technology Corporation
AES/EBU 2-CHANNEL AND S/PDIF 2-CHANNEL
The AES/EBU connectors or the S/PDIF connectors on the rear panel are available for transferring
digital audio. They can also be used to receive a clock signal from a master clock or another digital audio
device as well as transmit the master clock signal. Only one set of connectors is enabled at a time.
To switch between AES/EBU 2-Channel and S/PDIF 2-Channel:
Use the key, the and keys and the
key to go to the MAIN MENU / I/O
MENU /DIG 2-CH OUTPUT and press the
key.
Use the and keys to select AES/EBU or S/PDIF and press the key.
AES/EBU MULTI-CHANNEL
The optional AES/EBU multi-channel connectors on the rear panel are available for transferring digital
audio. They can also be used to receive a clock signal from a master clock or another digital audio
device, or to transmit the master clock signal.
If there are no AES/EBU cards installed an alert dialogue will state: NO AES MULTI-CH
CARD INSTALLED.
ADAT
The optional ADAT optical connectors on the rear panel are available for transferring digital audio. They
can also be used to receive a clock signal from a master clock or another digital audio device, or to
transmit the master clock signal.
If there are no ADAT cards installed an alert dialogue will state: NO ADAT CARD
INSTALLED.
TDIF
The optional TDIF connectors on the rear panel are available for transferring digital audio. They can also
be used to receive a clock signal from a master clock or another digital audio device, or to transmit the
master clock signal. The clock embedded in the TDIF audio signal is a different clock than TDIF Word
Sync.
If there are no TDIF cards installed an alert dialogue will state: NO TDIF CARD
INSTALLED. Purpose built TDIF cables must be used; pin-to-pin cables will not work.
