The number of channels supported by the installed card.
For RADAR this value will always be 24 channels.
(IF MADI CARD PRESENT)
These settings allow verification of incoming MADI-
specific data, and set output emphasis to On or Off.
This dialogue reads the indicator flag for the selected
input pair. Use the and arrow keys to select a
MADI input pair with a valid signal and the sample rate
will be displayed in the dialogue.
In the early days of digital, emphasis was used to
artificially boost the level of high frequency signal content
so that it could be quantized at a higher resolution. The
EMPHASIS IN dialogue indicates if the incoming MADI
signal is using emphasis or not.
Use this dialogue to turn the emphasis flag on and off for
the MADI output signal. When it is turned on it indicates
to the receiving device that the digital audio stream has
been recorded with emphasis and it should be decoded
accordingly.
Since RADAR does not decode emphasis nor store the
emphasis flag for audio recorded with emphasis, the
emphasis flag should be turned ON if the digital audio
recorded has previously been encoded with emphasis.
Emphasis is rarely, if ever, used in the industry today and
these options are included primarily for dealing with
legacy recordings.
Allows the user to select MADI modes. NON-LEGACY
mode is true 96 kHz.
Allows the user to select channels 1-24 or 25-48 from the
incoming MADI stream.
This dialogue is for setting the MADI digital-in format.
RADAR will accept clocking information on either format
regardless of this setting.
This option is for updating MADI firmware. For further
instructions refer to CONFIGURATION: DIGITAL I/O: MADI
FIRMWARE UPDATES
MADI SETTINGS:
INSTALL FIRMWARE
MADI SETTINGS:
COAX/OPTICAL IN
MADI SETTINGS:
INTERLACE (48CH)
MADI SETTINGS:
LEGACY MODE (96K)
MADI SETTINGS:
EMPHASIS OUT
MADI SETTINGS:
EMPHASIS IN
MADI SETTINGS:
SAMPLE RATE IN
MAIN/I/O MENU:
MADI SETTINGS
TDIF SETTINGS:
CARD TYPE
