This provides a way to test network communication by
sending small packets of data across the network.
The default IP address is the server ID
address set in the SERVER PREFS .
This function determines the information included in the
debug log. See OPERATIONS: DISK DIAGNOSTICS: RADAR
DEBUG for more information.
This option allows the user to save debugs to be
forwarded to iZ Support. Select from CURRENT LOG,
THE LAST 5 LOGS, LAST 20 LOGS , ALL LOGS, or
SELECT which logs to be saved. These logs can be
saved in text format or as a zip file to any disk or network
drive.
See OPERATIONS: DISK DIAGNOSTICS: RADAR DEBUG for
more information.
This function allows the debug log to be emailed directly
to iZ Support. See OPERATIONS: DISK DIAGNOSTICS:
RADAR DEBUG for more information.
This function restarts the background BeOS Desktop
which can then be accessed via the KC-24 by holding
down the key and pressing the key. At the BeOS
Desktop, access debug logs, rename/copy/delete
folders/files on the D:ARCHIVE partition, etc. Essentially
typical computer desktop operations.
The BeOS desktop also gives access to
the system partition (RADAR24BE)
which contains the software required to
run RADAR. Do NOT tamper with this
partition unless given implicit instructions
from iZ Technology Support personnel.
This function resets RADAR settings to the factory
defaults.
MAIN/DIAG MENU:
PING IP ADDRESS
MAIN/DIAG MENU:
EMAIL DEBUG
MAIN/DIAG MENU:
FACTORY SETTINGS
MAIN/DIAG MENU:
RESTART DESKTOP
MAIN/DIAG MENU:
SAVE DEBUG
MAIN/DIAG MENU:
CONFIGURE DEBUG
