Table 71: Optical Interface Support for SFP+ Transceivers (continued)
ValueSpecification
Ethernet
Standard
JNP-SFP-10G-BX10D
Used in conjunction with JNP-SFP-10G-BX10U
Model number10GBASE-BX-D
9.95328 GBd +/- 20 ppm
10.3125 GBd +/- 100 ppm
Rate
LC/PCConnector type
SingleFiber count
1320 nm to 1340 nmTransmitter wavelength
(range)
1260 nm to 1280 nmReceiver wavelength (range)
–8.2 dBMAverage minimum launch
power
0.5 dBmAverage maximum launch
power
–14.4 dBmAverage receive power
(minimum)
0.5 dBmAverage receive power
(maximum)
–12.6 dBmReceiver sensitivity (OMA)
(maximum)
–10.3 dBmStressed receiver sensitivity
(OMA) (maximum)
Type B1.1, B1.3 SMFFiber type
9/125 µmCore/cladding
10 km (6.21 miles)Distance
AvailableDOM support
YesSupport for Virtual Chassis
configuration
Junos OS for EX Series switches, Release 14.1X53-D35 or laterSoftware required
125Copyright © 2017, Juniper Networks, Inc.
Chapter 8: Transceiver and Cable Specifications
