Table 71: Optical Interface Support for SFP+ Transceivers (continued)

ValueSpecification

Ethernet

Standard

JNP-SFP-10G-BX10U

Used in conjunction with JNP-SFP-10G-BX10D

Model number10GBASE-BX-U

9.95328 GBd +/- 20 ppm

10.3125 GBd +/- 100 ppm

Rate

LC/PCConnector type

SingleFiber count

1260 nm to 1280 nmTransmitter wavelength

(range)

1320 nm to 1340 nmReceiver wavelength (range)

–8.2 dBmAverage minimum launch

power

0.5 dBmAverage maximum launch

power

–14.4 dBmAverage receive power

(minimum)

0.5 dBmAverage receive power

(maximum)

–12.6 dBmReceiver sensitivity (OMA)

(maximum)

–10.3 dBmStressed receiver sensitivity

(OMA) (maximum)

Type B1.1, B1.3 SMFFiber type

9/125 µmCore/cladding

10 km (6.21 miles)Distance

AvailableDOM support

YesSupport for Virtual Chassis

configuration

Junos OS for EX Series switches, Release 14.1X53-D35 or laterSoftware required
