AKD2G-S Installation Manual, Safety 1 | 8 Electrical Installation
8.10.12.12 X41 Hall Feedback
This feedback type only supports operating in Torque mode and Velocity mode.
If cable lengths of more than 25m are planned, please consult customer support.
Type FBx.INDENTIFIED Up Frequency Limit
Hall Only 112 5.1V ± 3.5% 1 MHz
For more information concerning Hall feedback setting refer to WorkBench Online Help.
8.10.12.13 X41 SSI Feedback
Sychronous Serial Interface (SSI) is a standard industrial serial interface based on RS-422 standards.
If cable lengths of more than 25m are planned, please consult customer support.
Type FBx.INDENTIFIED Up Frequency Limit
SSI (Sychronous Serial Interface) 136 5.1V ± 3.5% 1 MHz
■Optional
138 Kollmorgen | kdn.kollmorgen.com | June, 2023
