8.2 Guide to electrical installation
Kollmorgen recommends to install the drive electrical system as follows:
1. Select cables in accordance with IEC 60204 ( # 55).
2. Install shielding and ground the drive.
For EMC-compliant shielding and grounding, see ( # 58).
Ground the mounting plate, motor housing and CNC-GND of the control system.
3. For functional safety information, see ( # 179).
4. Wire the drive and connectors.
Observe the "Recommendations for EMI noise reduction": ( # 58).
l
Wire the "Ready to Operate" contact into the emergency off circuit of the system.
l
Connect the digital control inputs and outputs.
l
Connect up analog ground (also if a fieldbus is used).
l
Connect the analog input source, if required.
l
Connect the motor (hybrid cable or power, brake and feedback cables).
l
Connect shielding at both ends.
l
If required, connect the external regen resistor (with fusing).
l
Connect the mains filter FN2090/FN3288 with AKD2G-Sxx-6V (with shielded lines between filter and
drive) for second environment requirements to product category C2.
l
Connect the auxiliary voltage supply
l
Connect the main electrical supply.
Check maximum permitted voltage value ( # 35).
l
Check proper use of residual-current circuit breakers (RCD): ( # 19).
l
Connect the PC ( # 148) for setting up the drive.
5. Check the wiring against the wiring diagrams:
Overview AKD2G single axis ( # 66)
Overview AKD2G dual-axis ( # 68)
Connector pinout ( # 69)
Mains power supply: ( # 81)
Logic power supply: ( # 91)
DC Bus Link: ( # 92)
External Regen Resistor: ( # 95)
Motor single cable connection: ( # 97)
Motor dual cable connection: ( # 99)
Motor Holding Brake: ( # 101)
Feedback Connection ( # 104)
Encoder emulation: ( # 139)
Electronic gearing: ( # 139)
Master Slave: ( # 141)
EtherNet Fieldbus interface: ( # 142)
CAN-Bus interface: ( # 145)
Service interface: ( # 148)
Modbus interface: ( # 149)
Digital and analog I/O: ( # 150)
Functional Safety option 1: ( # 183)
AKD2G-S Installation Manual, Safety 1
