AKD2G-S Installation Manual, Safety 1 | 14 Requirements to User Documentation, Revision 1.12
14.2 IEC 61508-2 Annex D Requirements to User Documentation
ID
(green=done
for all FS)
Requirements
Realized
(green=done for FSx)
61508-31a
Functional specification of the functions capable of
being performed
FS1: (Available Safety Functions, ➜ # 183)
61508-31b
Identification of the hardware and/or software
configuration of the compliant item to enable
configuration management of the E/e/PE safety-
related system in accordance with 6.2.1 of IEC
61508-1
FS1:(Safety Manual for FS1, ➜ # 179)
61508-31c
Constraints on the use of the compliant item and/or
assumptions on which analysis of the behaviour or
failure rates of the item are based
Use (Use as directed, ➜ # 181)
Prohibited (Prohibited use, ➜ # 181)
Environment (Enclosure, wiring, ➜ # 182)
61508-32h
Any periodic proof test and/or maintenance
requirements.
FS1: STO (Diagnostic test, ➜ # 183)
61508-32i
For those failure modes, in respect of a specified
function, that are capable of being detected by
external diagnostics, sufficient information shall
be provided to facilitate the development of an
external diagnostics capability. The information
shall include details of failure modes and for those
failure modes the failure rates.
FS1: STO (Safety Faults,Safety Warnings, ➜ # 190)
61508-32j The hardware fault tolerance.
FS1: (The hardware fault tolerance is HFT = 1 according to
IEC 61508. Two faults might lead to loss of the safety
functions., ➜ # 183)
61508-32k
The classification as type A or type B of that part of
the compliant item that provides the function (see
/1/ 7.4.4.1.2 and 7.4.4.1.3)
FS1: STO (STO is suited for SIL 2 according to IEC 62061
and PLd / Cat.3 according to ISO 13849-1. STO is a type A
subsystem according to IEC 61508., ➜ # 185)
61508-33a
The systematic capability of the compliant item or
that part of the element that provides the function.
FS1: (The systematic capability according to IEC 61508 for
the safety-related subsystems of the drive are SC = 2. TM =
20 Years, SFF = 75%., ➜ # 183)
61508-33b
Any instructions or constraints relating to the
application of the compliant item, relevant to the
function, that should be observed in order to
prevent systematic failures of the compliant item.
FS1/2/3: Full Installation Manual including Safety Manual.
