AKD2G-S Installation Manual, Safety 1 | 10 Safety Manual for FS1
10.1.4 Enclosure, wiring
Enclosure
Since the drive meets IP20, you must select an enclosure that permits safe operation of the drive. The enclosure
must at least meet IP54 .
Transport in accordance with IEC 61800-2
Transport only in the manufacturer’s original recyclable packaging.
Temperature -25 to +70 °C, maximum rate of change 20 K/hour, class 2K3.
Relative Humidity max. 95% at +40°C, no condensation, class 2K3.
Shock
NOTICE: Avoid shocks while transporting. AKD2G modules are tested for environmental class 2M1
of IEC 60721-3-2.
Storage in accordance with IEC 61800-2
Temperature -25 to +55°C, maximum rate of change 20K/hour, class 1K4.
Relative Humidity 5 to 95% , no condensation, class 1K3.
Operation in accordance with IEC 61800-2
Environmental Class Environmental class 3K3
Temperature
Internal regen resistor used:
l
0 to +40°C under rated conditions
l
+40 to +60°C with current derating 3 % per Kelvin
Internal regen resistor not used:
l
0 to +50°C under rated conditions
l
+50 to +60°C with current derating 2% per Kelvin
Relative Humidity 5 to 85%, no condensation, IEC61800-2 class 3K3
Site Altitude
l
Up to 1000 m above mean sea level (AMSL): no restriction
l
1,000 to 2,000 m AMSL: power derating 1.5%/100 m
l
Maximum altitude: 2000 m AMSL
Drive EMC Immunity Increased immunity according to EN 61800-5-2
Drive Pollution Level Pollution level 2 as per IEC 60664-1
Drive Vibration Class Class 3M1 according to IEC 61800-2
Drive Shock Class Class L according to IEC 61800-2
Drive Protection Class IP20 according to IEC 60529
Enclosure Minimum cabinet size (WxHxD): 406 x 406 x 254 mm
Enclosure Protection At least IP 54 according to IEC 60529
Wiring
Wiring inside the specified enclosure (IP54) must meet the requirements of the standard IEC60204-1 and
ISO13849-2 (Table D.4). Use copper wires, 0.5 mm² (20 awg), wire ferrules. Maximum distance for unshielded I/O
lines is 3 m inside the cabinet. If the I/O cable leaves the cabinet, it must be EMC shielded.
Wiring outside the specified enclosure must be laid durably protected from outside damage (for example, by laying
the cable in a duct, placed in different sheathed cables, or protected individually by grounding connection).
When wiring the digital inputs and outputs, take care that short circuits between the inputs, outputs, or to
supply lines are avoided.
182 Kollmorgen | kdn.kollmorgen.com | S103, March 2023
