AKD2G-S Installation Manual, Safety 1 | 6 Technical description and data
6.5.2.4 Output data, type AKD2G-Sxx- (D)
Drive current and power output values are listed for Axis1/Axis2.
Parameter Units 6V03D 6V06D 7V03D 7V06D
Continuous output current (± 3%) Arms 3/3 6/6 3/3 6/6
Peak output current (for 5s, ±3%) Arms 9/9 18/18 9/9 18/18
Continuous motor shaft output power at rated input current
at 1 x 120 VAC kW 0.22/0.22 0.44/0.44 - -
at 1 x 240 VAC kW 0.44/0.44 0.875/0.875 0.44/0.44 0.875/0.875
at 3 x 120 VAC kW 0.31/0.31 0.625/0.625 - -
at 3 x 240 VAC kW 0.625/0.625 1.25/1.25 0.625/0.625 1.25/1.25
at 3 x 400 VAC kW - - 1.05/1.05 2.1/2.1
at 3 x 480 VAC kW - - 1.25/1.25 2.5/2.5
at 170 VDC kW 0.31/0.31 0.625/0.625 - -
at 340 VDC kW 0.625/0.625 1.25/1.25 0.625/0.625 1.25/1.25
at 565 VDC kW - - 1.05/1.05 2.1/2.1
at 680 VDC kW - - 1.25/1.25 2.5/2.5
Peak output power (for 1 s)
at 1 x 120 VAC kW 1.1/1.1 2.1/2.1 - -
at 1 x 240 VAC kW 2.1/2.1 4.2/4.2 - -
at 3 x 120 VAC kW 1.5/1.5 3.0/3.0 - -
at 3 x 240 VAC kW 3.0/3.0 6.0/6.0 3.0/3.0 6.0/6.0
at 3 x 400 VAC kW - - 5.0/5.0 10/10
at 3 x 480 VAC kW - - 6.0/6.0 12/12
at 170 VDC kW 1.5/1.5 3.0/3.0 - -
at 340 VDC kW 3.0/3.0 6.0/6.0 3.0/3.0 6.0/6.0
at 565 VDC kW - - 5.0/5.0 10/10
at 680 VDC kW - - 6.0/6.0 12/12
Fan noise emission at 1m, min/max dB(A) < 50 / 60
Thermal dissipation, disabled W 15 15 15 15
Thermal dissipation at rated current W 90 150 120 210
Motor inductance
minimum at 120 VAC mH 1.2/1.2 0.6/0.6 - -
minimum at 240 VAC mH 2.4/2.4 1.2/1.2 3.1/3.1 1.9/1.9
minimum at 400 VAC mH - - 5.1/5.1 3.2/3.2
minimum at 480 VAC mH - - 6.1/6.1 3.8/3.8
maximum mH 240/240 120/120 610/610 380/380
Regeneration Braking (➜ # 40)
Brake output
Voltage (±10%) VDC 24
Voltage power saving VDC 12 to 24
Output under current fault mA 100 (required for fault detection)
Output over current fault A 2.25 (required for fault detection)
Output current, maximum A 2.1 per brake
38 Kollmorgen | kdn.kollmorgen.com | June, 2023
