AKD2G-S Installation Manual, Safety 1 | 5 Package
5.3 Part Number Scheme
Use the part number scheme for product identification only.
Do not use it for the order process as not all features can always be combined among each other.
l
Mating connectors are not included in the package of a standard drive.
l
Mating connectors are included when the drive is ordered with accessories (append “-A”
to the model number).
l
Mating connectors X1, X2, RJ25, RJ45, SubD are always part of the used cables.
Format
S Servo IP20
Drive Version
P Position Indexer with motion tasks
Family
AKD2G AKD 2nd generation
Connector Options*
Single Axis Dual Axis
00 X4*, X5*, X21, X22
Standard
X21, X22
Standard
F3 +X23
(Feedback 3)
+X23
(Feedback 3)
IO +X22 (I/O)
–
DX X22 + X23
–
*X4 & X5 are only available on 3, 6
and 12 Amp drives with FS2-3 and are
standard on 24 Amp drives.
Customization
0000 Standard
A000 Coated PCBs
Connectors
A with connectors (except
X1/X2 and X23)
Voltage
6V 120/240 V
!"
1Ø/3Ø
7V 240/480 V
!"
3Ø
Connectivity Option
N Analog
E EtherCAT
®
C CANopen
®
P PROFINET
®
IRT
I Ethernet/IP™
Current Rating
03 3 A
#$%
06 6 A
#$%
12 12 A
#$%
24 24 A
#$%
Options
S Single Axis
D Dual Axis
Functional Safety (FS)
1 STO, safe inputs (SIL2, PLd)
Platform Revision
A MAP Revision A
AKD2G - S P E - 7V 06 S - A 1 F3 - 0000 - A
*See connector options feedback, I/O, and brake availability on the following page.
Example AKD2G-SPE-7V06S-A1IO-0000
AKD2G IP20 housing, position indexer, EtherCAT, 240 V to 480 V mains supply, 6 A rated current, single axis,
Plattform Revision A, dual channel STO SIL2 PLd, with additional I/O connector X22, uncoated, no mating
connectors.
Example AKD2G-SPE-6V03D-A1F3-A000-A
AKD2G IP20 housing, position indexer, EtherCAT, 120 V to 240 V mains supply, 2 x 3 A rated current, dual axis,
Plattform Revision A, dual channel STO SIL2 PLd, with all possible connectors (X21 + X22 + X23), PCBs coated,
with mating connectors.
