8.16.5.5 Digital-Out 9, Relay contacts
Digital-Out 9 is programmable with WorkBench.
By default, the output function is defined as ready to operate output by action parameter.
If an inductive load (relay or similar) is used, a freewheeling diode must be added to the load.
Technical characteristics
l
Relay output, max. 30 VDC or 42 VAC, 1 A
l
Galvanic isolation for 24 VDC from PE
l
Time to close: max. 10 ms
l
Time to open: max. 10 ms
AKD2G-S Installation Manual, Safety 1
Kollmorgen | kdn.kollmorgen.com | June, 2023 161
