AKD2G-S Installation Manual, Safety 1 | 6 Technical description and data
6.5.1.4 Output data, type AKD2G-Sxx- (S)
Units 6V03S 6V06S 6V12S 7V03S 7V06S 7V12S 7V24S
Continuous output current (± 3%) Arms 3 6 12 3 6 12 24
Peak output current (for 5s, ±3%) Arms 9 18 30 9 18 30 72
Continuous motor shaft output power at rated input current
at 1 x 120 VAC kW 0.22 0.44 0.875 - - - -
at 1 x 240 VAC kW 0.44 0.875 1.8 0.44 0.875 1.8 2.5
at 3 x 120 VAC kW 0.31 0.625 1.25 - - - -
at 3 x 240 VAC kW 0.625 1.25 2.5 0.625 1.25 2.5 5.0
at 3 x 400 VAC kW - - - 1.05 2.1 4.2 8.3
at 3 x 480 VAC kW - - - 1.25 2.5 5.0 10.0
at 170 VDC kW 0.31 0.625 1.25 - - - -
at 340 VDC kW 0.625 1.25 2.5 0.625 1.25 2.5 5.0
at 565 VDC kW - - - 1.05 2.1 4.2 8.3
at 680 VDC kW - - - 1.25 2.5 5.0 10.0
Peak output power (for 1 s)
at 1 x 120 VAC kW 1.1 2.1 4.1 - - - -
at 1 x 240 VAC kW 2.1 4.2 6.3 - - - 12
at 3 x 120 VAC kW 1.5 3 4.5 - - - -
at 3 x 240 VAC kW 3.0 6.0 9.0 3.0 6.0 10 24
at 3 x 400 VAC kW - - - 5.0 10 16.5 40
at 3 x 480 VAC kW - - - 6.0 12 20 48
at 170 VDC kW 1.5 3 4.5 - - - -
at 340 VDC kW 3.0 6.0 9.0 3.0 6.0 10 24
at 565 VDC kW - - - 5.0 10 16.5 40
at 680 VDC kW - - - 6.0 12 20 48
Fan noise emission at 1m, min/max dB(A) < 50 / 60 < 50 /76
Thermal dissipation, disabled W 12 12 12 12 12 12 15
Thermal dissipation at rated current W 50 80 140 65 105 210 395
Motor inductance
minimum at 120 VAC mH 1.2 0.6 0.3 - - - -
minimum at 240 VAC mH 2.4 1.2 0.6 3.1 1.5 1.1 0.5
minimum at 400 VAC mH - - - 5.1 2.6 1.8 0.85
minimum at 480 VAC mH - - - 6.1 3.1 2.1 1.0
maximum mH 240 120 60 610 310 180 80
Regeneration Braking (➜ # 40)
Brake output
Voltage (±10%) VDC 24
Voltage power saving VDC 12 to 24
Output under current fault mA 100 (required for fault detection)
Output over current fault A 2.25 (required for fault detection)
Output current, maximum A 2.1
36 Kollmorgen | kdn.kollmorgen.com | June, 2023
