Kollmorgen AKD 2G-S Series User Manual

6.5 Electrical data
6.5.1 Single axis variants (S)
6.5.1.1 Mains supply data, 1 phase AC, type AKD2G-Sxx- (S)
Input data Units 6V03S 6V06S 6V12S
Operational supply voltage (line to line) VAC 12 to 265
Rated supply voltage VAC 100 to 240
Rated supply input frequency (±5%) Hz 50 to 60
Permitted switch on/off frequency 1/h 30
Rated input VA at 240 V kVA 1.0 1.7 3.1
Rated input current A 4.0 7.1 13
Max. inrush current A 10
Rated DC bus link voltage VDC 300
6.5.1.2 Mains supply data, 3 phase AC, type AKD2G-Sxx- (S)
Input data Units 6V03S 6V06S 6V12S 7V03S 7V06S 7V12S 7V24S
Operational supply voltage (Line to Line) VAC 12 to 265 24 to 525
Rated supply voltage VAC 100 to 240 200 to 480
Rated supply input frequency (±5%) Hz 50 to 60
Permitted switch on/off frequency 1/h 30
Rated input VA at 240 V (* at 480 V) kVA 1.3 2.2 4.0 2.7* 4.4* 7.2* 15.2*
Rated input current A 3.2 5.3 9.7 3.2 5.3 8.7 18.3
Max. inrush current A 10
Rated DC bus link voltage VDC 140 to 340 280 to 680
6.5.1.3 Mains supply data, DC, type AKD2G-Sxx- (S)
Input data Units 6V03S 6V06S 6V12S 7V03S 7V06S 7V12S 7V24S
Operational supply voltage (DC+ to DC-) VDC 17 to 370 34 to 740
Rated supply voltage VDC 100 to 340 200 to 680
Permitted switch on/off frequency 1/h 30
Rated input power at 340 V (* at 680 V) kW 0.62 1.25 2.5 1.25* 2.5* 5.0* 10*
Rated input current A 2.0 4.0 8.0 2.0 4.0 8.0 16
Max. inrush current through AC input A 10
Rated DC bus link voltage VDC 100 to 340 200 to 680
AKD2G-S Installation Manual, Safety 1
Kollmorgen | kdn.kollmorgen.com | June, 2023 35
