6.1 The AKD2G Family of Digital Drives
Available AKD2G-SP (Position Indexer) versions
Connectivity Rated Voltages Current Axis Rev Funct. Safety
N-: Analog
C-: CANopen
E-: EtherCAT
P-: PROFINET
I-: EtherNet/IP
6V:
120/240VAC 1~
240VAC 3~
170/340 VDC
7V:
240/400/480VAC 3~
340/565/680 VDC
03: 3 A
06: 6 A
12: 12 A
24: 24 A
S-: Single
D-: Dual I1=I2
A 1: SIL2 STO
Connector Options
Single Axis Dual Axis
00: Basis (X21, 24 A model: +X4, +X5)
IO: Basis +X22
F3: Basis +X23
DX: Basis +X22, +X23
00: Basis (X21, X22)
F3: Basis +X23
Standard features
l
Single axis or dual axis in one housing
l
Supply voltages:
l
DC
l
AC single phase, split phase, three phase AC neutral or leg grounded
l
Single or group supply, single or group mains fusing
l
EtherNet Fieldbus on board, TCP/IP service channel and Modbus on board
l
SFD3, HIPERFACE DSL motor feedback support on board
l
Support for many conventional motor feedback types
l
Step / Direction input on board
l
Encoder emulation on board
l
Use with synchronous servomotors, linear motors, and induction machines
Power section
l
Single or three phase AC supply, 5% to 110% of rated AC voltage over 47 to 63 Hz. Connection to higher AC
voltage mains only by using isolating transformer.
l
DC supply, voltage range 5% to 110% of rated DC voltage. Fusing to be provided by the user.
l
Three phase bridge rectifier, integral soft-start circuit.
l
DC bus link voltage can be connected in parallel for power sharing.
l
Floating current sensors measure actual motor current
l
Regenerative circuit with dynamic distribution of the generated power between several drives on the same DC
bus link circuit.
l
Internal regen resistor for all models, optional external regen resistor if required.
Functional Safety Options
l
FS1: STO; SIL2 PLd, command by I/O (➜ # 183).
AKD2G-S Installation Manual, Safety 1
Kollmorgen | kdn.kollmorgen.com | June, 2023 31
