Kyocera FS-C8600DN Service Manual

2MN/2N1
1-3-75
U140 Setting: [Mag AC]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Setting: [Sleeve Freq]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Setting: [Sleeve Duty]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
*: 55 ppm model only.
3. Press the OK key. The value is set.
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
C Developer magnet roller AC bias
for cyan
0 to 255 200 200
M Developer magnet roller AC bias
for magenta
0 to 255 200 200
Y Developer magnet roller AC bias
for yellow
0 to 255 200 200
K Developer magnet roller AC bias
for black
0 to 255 160 160
B/W* Developer magnet roller AC bias
in black/white mode
0 to 255 - 160
Display Description
Setting
range
Initial setting
45ppm 55ppm
Normal Developer sleeve roller fre-
quency
0 to 6200 5345 5511
B/W* Developer sleeve roller fre-
quency in black/white mode
0 to 6200 - 5345
Half Developer sleeve roller fre-
quency (half speed)
0 to 6200 5345 5345
3/4* Developer sleeve roller fre-
quency at 3/4 times of line speed
0 to 6200 5345 5345
Display Description
Setting
range
Initial setting
45ppm 55ppm
Normal Developer sleeve roller duty 0 to 99 68 68
B/W* Developer sleeve roller duty in
black/white mode
0 to 99 - 68

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
