Kyocera FS-C8600DN Service Manual

2MN/2N1-1
1-3-84
U161 Setting: [Print]
1. Select the item to be set.
2. Change the setting value using the numeric keys.
3. Press the OK key. The value is set.
Setting: [LowPower Mode]
1. Select the item to be set.
Initial setting: Mode1
2. Press the OK key. The setting is set.
Setting: [Grain Mode]
1. Select the item to be set.
Initial setting: Mode0
Press the OK key. The setting is set.
Completion
Press the Back key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Setting
range
Initial setting
45ppm 55ppm
F.S.Print(C) Temperature at maximum
print speed (Center)
130 to 200
(°C)
170 175
Dup Shift(C) Temperature at duplex
printing (Center)
-20 to 20
(°C)
55
Display Description
Mode0 Not used normally (use when a fusing problem has occurred at
continuous printing in mode 1, however, use caution that mode
0, when used continously, can deteriorate the durability of the
fuser rollers).
Mode1 Fuser control temperature reduction mode (For normal users)
Mode2 Large volume output mode (For users who repeatedly print
approximately 1500 sheets at a time)
Display Description
Mode0
Existing level (No special treatment)
Mode1
Setting the grain mode
Mode2
More improvements

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
