Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-29
YC26
A11 FSR_RLS_DR_C
W
O 0/24 V DC FURM: On/Off (CW)
Connected to
fuser unit and
fuser IH PWB
A12 GND - - Ground
A13 FSR_SIZE_SENS I 0/3.3 V DC FUES: On/Off
A14 +5V O 5 V DC 5 V DC power to FUES
A15 GND - - Ground
A16 FSR_RLS_SENS I 0/3.3 V DC FURS: On/Off
A17 +5V O 5 V DC 5 V DC power to FURS
A18 GND - - Ground
A19 FSR_BLT_PLS I 0/3.3 V DC FUBLS: On/Off
A20 +5V O 5 V DC 5 V DC power to FUBLS
B1 PRESS_HEART_
REM
- - Not used
B2 IH_RXD I 0/3.3 V DC (pulse) Serial communication data signal
B3 IH_TXD O 0/3.3 V DC (pulse) Serial communication data signal
B4 ROTATION O 0/3.3 V DC FIH control signal
B5 IH_HEAT_REM O 0/3.3 V DC FIH: On/Off
B6 +3.3V2 O 3.3 V DC 5 V DC power to FIH
B7 GND - - Ground
B8 GND - - Ground
B9 PRESS_TH I Analog FTH4 detection signal
B10 GND - - Ground
B11 EDGE_TH I Analog FTH2 detection signal
B12 GND - - Ground
B13 GUIDE_TH1 - - Not used
B14 GND - - Ground
B15 GUIDE_TH2 I Analog FTH3 detection signal
B16 MAIN_TH2 I Analog FTH1 detection signal
B17 MAIN_TH1 I Analog FTH1 detection signal
B18 GND - - Ground
B19 +24V1 O 24 V DC 24 V DC power to BRFM
B20 BRIDGE_FAN O 0/24 V DC BRFM: On/Off
YC27
1 GND - - Ground
Connected to
RFID PWB,
toner motor
K/M/C/Y and
screw sen-
sor K/M/C/Y
2 SDA I/O 0/3.3 V DC (pulse) EEPROM data signal
3 SCL I 0/3.3 V DC (pulse) EEPROM clock signal
4 3.3V2 O 3.3 V DC 3.3 V DC power to RFPWB
5 24V1 O 24 V DC 24 V DC power to TM-Y
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
