Kyocera FS-C8600DN Service Manual

2MN/2N1
2-3-31
YC46
18
HSYNC_AP I
0/3.3 V DC (pulse)
Image control signal
Connected to
main PWB
19
HSYNC_AN I
0/3.3 V DC (pulse)
Image control signal
20
VSYNC_DP I
0/3.3 V DC (pulse)
Image control signal
21
VSYNC_DN I
0/3.3 V DC (pulse)
Image control signal
22
VSYNC_CP I
0/3.3 V DC (pulse)
Image control signal
23
VSYNC_CN I
0/3.3 V DC (pulse)
Image control signal
24
VSYNC_BP I
0/3.3 V DC (pulse)
Image control signal
25
VSYNC_BN I
0/3.3 V DC (pulse)
Image control signal
26
VSYNC_AP I
0/3.3 V DC (pulse)
Image control signal
27
VSYNC_AN I
0/3.3 V DC (pulse)
Image control signal
28
GND
- - Ground
29
SAR_VCLK_P I
0/3.3 V DC (pulse)
Clock signal
30
SAR_VCLK_N I
0/3.3 V DC (pulse)
Clock signal
31
GND
- - Ground
32
SAR_CH3_P I
0/3.3 V DC (pulse)
Image control signal
33
SAR_CH3_N I
0/3.3 V DC (pulse)
Image control signal
34
GND
- - Ground
35
SAR_CH2_P I
0/3.3 V DC (pulse)
Image control signal
36
SAR_CH2_N I
0/3.3 V DC (pulse)
Image control signal
37
GND
- - Ground
38
SAR_CH1_P I
0/3.3 V DC (pulse)
Image control signal
39
SAR_CH1_N I
0/3.3 V DC (pulse)
Image control signal
40
GND
- - Ground
Connector Pin Signal I/O Voltage Description

Kyocera FS-C8600DN Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	9600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	5.4 s
Time to first page (color, normal)	6.6 s
Print speed (black, normal quality, A3)	22 ppm
Print speed (black, normal quality, A4/US Letter)	45 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	-
Page description languages	Diablo 630, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	500 sheets
Maximum input capacity	7650 sheets
Multi-Purpose tray input capacity	150 sheets
Paper tray media types	Banner, Plain paper, Thick paper
ISO A-series sizes (A0...A9)	A3, A4, A5
Maximum ISO A-series paper size	A3
Wi-Fi	No
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet
Memory slots	2
Storage media	HDD
Processor family	PowerPC
Compatible memory cards	CF
Maximum internal memory	2048 MB
Internal storage capacity	160 GB
Sound power level (standby)	33.9 dB
Sound pressure level (printing)	52.3 dB
Certification	GS, TüV, CE
Product color	Black
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1140 W
Power consumption (standby)	170 W
Power consumption (printing)	1000 W
Power consumption (PowerSave)	15 W
Sustainability certificates	ENERGY STAR
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	787 mm
Width	672 mm
Height	744 mm
