Model 831 Manual 831 Components 3-5
Keypad
The 831 meter has a 13 button keypad. This section
describes the buttons on the keypad.
FIGURE 3-4 shows the 831 keys.
FIGURE 3-4 Model 831 Keys
Softkeys
The three push button keys just beneath the display, on the
body of the Model 831, are called Softkeys.
Figure 3-5 shows the softkeys.
.
SOFTKEYS:
Left
Center
Right
RUN/PAUSE
STOP/STORE
UP
RIGHT
DOWN
LEFT
RESET
TOOLS
POWER
