Model 831 Manual Weather Measurement Using 831-INT 19-5
Vaisala Weather Station
Units
Units are not configurable using the Vaisala Weather Station
(SEN-031). However, they will follow English or SI units as
configured in the System Properties dialog described in
Chapter 18.
Wind Setup
The Wind Setup menu is shown in FIGURE 19-7.
FIGURE 19-7 Weather Wind Menu
Wind Dir: Choose Compass or Degrees for the display (i.e.,
ENE vs. 70.0°)
Threshold: If the wind speed is above this threshold, it is
considered windy.
English SI
Wind mi/h m/s
Temperature
F C
Relative Humidity % RH % RH
Table 19-2 Vaisala Units
