15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00993
C00994
C00995
C00996
Parameter | Name:
C00993 | Flying restart fct: Int. time
Data type: UNSIGNED_16
Index: 23582
d
= 5C1E
h
Time constant of the angular difference controller of the flying restart function
• The time constant is to amount between 60 ... 300 ms.
Flying restart fct.
Setting range (min. value | unit | max. value) Lenze setting
0.0 ms 6000.0 power-related (see table
)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
Parameter | Name:
C00994 | Flying restart fct.: Current
Data type: INTEGER_16
Index: 23581
d
= 5C1D
h
Current to be injected during the flying restart process
•100% ≡ rated motor current (C00088
).
• The flying restart current should amount to 10 ... 25 % of the rated motor current.
Flying restart fct.
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 25.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00995 | SLPSM: Controlled current setpoint
Data type: UNSIGNED_16
Index: 23580
d
= 5C1C
h
From version 10.00.00
Sensorless control for synchronous motors (SLPSM)
Setting range (min. value | unit | max. value)
5.00 % 400.00
Subcodes Lenze setting Info
C00995/1 100.00 % SLPSM
: Controlled accelerating current
C00995/2 20.00 % SLPSM: Controlled standstill current
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00996 | SLPSM: Switching speed
Data type: INTEGER_16
Index: 23579
d
= 5C1B
h
From version 10.00.00
Sensorless control for synchronous motors (SLPSM)
Setting range (min. value | unit | max. value)
0.00 % 100.00
Subcodes Lenze setting Info
C00996/1 13.00 % SLPSM
: Switching speed, closed-loop control
C00996/2 8.00 % SLPSM
: Switching speed, open-loop control
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
