15 Parameter reference
15.2 Parameter list
1078
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01236
C01237
C01238
C01239
Parameter | Name:
C01236 | MCK: Speed follower
Data type: INTEGER_32
Index: 23339
d
= 5B2B
h
Speeds for position follower
Position follower
Setting range (min. value | unit | max. value)
-214748.3647 units/s 214748.3647
Subcodes Lenze setting Info
C01236/1 360.0000 units/s PosFollower: Sync. speed
• Synchronisation speed for approaching the setpoint
position of the master.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01237 | MCK: Acceleration follower
Data type: INTEGER_32
Index: 23338
d
= 5B2A
h
Accelerations for position follower
Position follower
Setting range (min. value | unit | max. value)
-214748.3647 units/s2 214748.3647
Subcodes Lenze setting Info
C01237/1 720.0000 units/s2 Pos follower: Sync. accel.
• Acceleration for ramp-up to synchronisation speed.
C01237/2 720.0000 units/s2 Pos follower: Sync. decel.
• Deceleration for synchronisation speed ramp-down
to standstill (to the setpoint position of the master).
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01238 | MCK: S-ramp time follower
Data type: UNSIGNED_16
Index: 23337
d
= 5B29
h
S-ramp times for position follower
•Setting "0 s" ≡ no rounding
Position follower
Setting range (min. value | unit | max. value)
0.000 s 10.000
Subcodes Lenze setting Info
C01238/1 0.000 s Pos follower: Sync. S-ramp time
• S-ramp time for the synchronisation speed ramps.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C01239 | Setpoint holding
Data type: UNSIGNED_32
Index: 23336
d
= 5B28
h
From version 12.00.00
Setpoint holding for bus runtime compensation
Setting range (min. value | unit | max. value) Lenze setting
0ms320ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
