Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1091
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01301
C01302
11 Absolute (Cw) on TP From version 06.00.00
Clockwise absolute positioning
• The zero position of the axis can be exceed in this
direction.
• The profile position corresponds to the target
position.
• After a touch probe is detected, the TP profile
(C01308/1...15
) is executed.
12 Absolute (Ccw) on TP From version 06.00.00
Counter-clockwise absolute positioning
• The zero position of the axis can be exceed in this
direction.
• The profile position corresponds to the target
position.
• After a touch probe is detected, the TP profile
(C01308/1...15
) is executed.
Subcodes Lenze setting Info
C01300/1 1: absolute (beeline) Profiles 1 ... 15: Positioning mode
C01300/...
C01300/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01300 | Profile data: Positioning mode
Data type: UNSIGNED_8
Index: 23275
d
= 5AEB
h
Parameter | Name:
C01301 | Profile data: Position
Data type: INTEGER_32
Index: 23274
d
= 5AEA
h
Selection of the positions for profiles 1 ... 15
Profile entry
Setting range (min. value | unit | max. value)
-214748.3647 unit 214748.3647
Subcodes Lenze setting Info
C01301/1 360.0000 unit Profiles 1 ... 15: Position
C01301/...
C01301/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01302 | Profile data: Speed
Data type: INTEGER_32
Index: 23273
d
= 5AE9
h
Selection of the maximum speeds for profiles 1 ... 15
Profile entry
Setting range (min. value | unit | max. value)
-214748.3647 unit/s 214748.3647
Subcodes Lenze setting Info
C01302/1 360.0000 unit/s Profiles 1 ... 15: Speed
C01302/...
C01302/15
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
