Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1270
17 Function library
17.1 Function blocks | L_CalcDiameter_1
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01050/1 0.001 Rev. 2.000 Diameter recalculation 0
• Number of revolutions after
which a diameter calculation is
executed.
• Setting is effective when bCalcRef
= FALSE.
• Initialisation: 1.000
C01050/2
0.001 Rev. 2.000 Diameter recalculation 1
• Number of revolutions after
which a diameter calculation is
executed.
• Setting is effective when bCalcRef
= TRUE.
• Initialisation: 0.100
C01051/1
0.010 s 3.000 Filter time constant for calculated
diameter values
• Initialisation: 1.000 s
C01052/1
0.00 % 100.00 Permissible diameter change in
opposite direction (web break
monitoring)
• Only relevant when bUnidirect =
TRUE.
• Referring to the maximum
diameter (wMaxDiameter).
• Initialisation: 10.00 %
C01057/1
0.000 mm 10000.000 Current diameter
•Read only
C01067/3
Invert. gearbox nMotorSpeedAct_v
0not inverted
1inverted
2 Automatically from MCK
Parameters Possible settings Info
