17 Function library
17.1 Function blocks | L_DFSET_1
1357
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01073/1 Setting is bit coded: setting
• Lenze setting: 0x02
Bit 0 Setpoint angle without gearbox
factor
0 = Evaluation of the setpoint angle
with gearbox factor.
1 = Evaluation of the setpoint angle
without gearbox factor.
Bit 1 Angle correction with polynomial 0 = Angle correction without
downstream polynomial.
1 = Angle correction with
downstream polynomial.
Bit 2 External angle correction 0 = Internal angle correction
1 = External angle correction
• From version 13.00.00
Bit 3 Reserved
...
Bit 7
C01074/1
0 16384 Divisor for actual value zero pulse
• Number of signals to be received
at least until synchronisation gets
active.
•Initialisation: 0 (≡ 1)
Note: The settings 0 and 1 are functionally
identical. If 0 or 1 is set, at least one pulse is
required in order that the synchronisation
gets active.
C01074/2
0 16384 Divisor for setpoint zero pulse
• Number of signals to be received
at least until synchronisation gets
active.
•Initialisation: 0 (≡ 1)
Note: The settings 0 and 1 are functionally
identical. If 0 or 1 is set, at least one pulse is
required in order that the synchronisation
gets active.
Parameters Possible settings Info
