17 Function library
17.1 Function blocks | L_SwitchPoint_1
1515
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
Parameters
dn2ndPoint_Sizex_p
DINT
Position switch point x: Position of the second switching point or size of the
switching window depending on the CenterMode set in C01064/x
:
When CenterMode = FALSE:
Position of the second switching point in [increments]
dn2ndPoint_Size_p must be higher than dnSwitchPoint_p.
When CenterMode = TRUE:
Size of the switching window in [increments]
Due to the symmetrical arrangement of the window around the first switching
point, uneven values are rounded to even values.
Only positive values are permissible.
Designator
Data type
Value/meaning
bOut1 ... bOut4
BOOL
Switching output 1 ... 4
TRUE The actual position is inside the defined switching window.
nState
INT
Status
1FB is not active
2OK
3 The data form resulting from the switching points are not plausible
(dnSwitchPoint_p, dn2ndPoint_Size_p, parameterised hysteresis).
Parameters Possible settings Info
C01062/1...4
0 μs 65535 Dead time for dead time
compensation
The resulting switching position is
not subject to a plausibility check.
•Lenze setting: 0μs
C01063/1...4
0 Incr. 65535 Switching hysteresis
•Lenze setting: 0incr.
C01064/1...4
CenterMode
Definition how the
dn2ndPoint_Size_p selection is
interpreted.
False dn2ndPoint_Size_p defines the
second switching point.
(Lenze setting)
True dn2ndPoint_Size_p defines the size
of the switching window.
C01065/1...4
0 ms 60000 Running time for position/time-
based cams
•Lenze setting: 0ms
0 ms = position-based cam
Designator
Data type
Information/possible settings
