5 Motor control (MCTRL)
5.15 Internal interfaces | System block "LS_MotorInterface"
314
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
nBoost_a
C00830/26 | INT
Process signal for the V
min
boost
• This signal is added to C00016
and has thus an increasing or decreasing effect.
• This signal serves to implement a load-dependent V
min
boost to improve the
torque behaviour in different load states, as for instance in case of operation in
generator or motor mode.
• Scaling: 16384 ≡ 100 % rated device voltage V
FU
(400 V or 230 V)
Adapting the Vmin boost
( 166)
 Stop!
Values selected too high may cause the motor to heat up due to the resulting
current!
bPosCtrlOn
C00833/27 | BOOL
Position/angle control
FALSE Deactivate position/angle control.
TRUE Activate position/angle control.
bDeltaPosOn
C00833/35 | BOOL
Activate position difference as setpoint selection
• In order to position the motor shaft, the position control
function can work
within the motor control function with the absolute position setpoint
dnPosSetValue_p or alternatively with the speed setpoint nSpeedSetValue_a and
the position difference dnDeltaPos_p.
FALSE Positioning with position setpoint dnPosSetValue_p.
TRUE Positioning with speed setpoint nSpeedSetValue_a and position
difference dnDeltaPos_p.
dnDeltaPos_p
C00834/4 | DINT
Position difference (following error input)
• Difference between setpoint position and actual position in [increments]
•Is used for position control
if bDeltaPosOn = TRUE.
• Scaling: 65535 ≡ 1 revolution
dnPosSetValue_p
C00834/5 | DINT
Absolute position setpoint in [increments]
•Is used for position control
if bDeltaPosOn = FALSE.
• Scaling: 65535 ≡ 1 revolution
bPosDerivativeOn
C00833/67 |BOOL
Create a setpoint for the speed controller from the position setpoint
• For highly dynamic control systems, the setpoint for the speed controller can be
created from the absolute position setpoint dnPosSetValue_p instead of the
speed setpoint nSpeedSetValue_a Position control/additive speed specification
TRUE Create a speed setpoint from the position setpoint.
• The absolute position setpoint dnPosSetValue_p is differentiated
and a speed value is created which is the setpoint for the speed
controller.
• Internal limitation of 65536 increments/ms.
bReserved01
C00833/68 | BOOL
Reserved
dnPosRefValue_p
C00834/6 | DINT
Home position in [increments]
• Scaling: 65535 ≡ 1 revolution
bQspOn
C00833/33 | BOOL
Quick stop
FALSE Deactivate quick stop
TRUE Activate quick stop
nPWMAngleOffset_a
C00830/32 | INT
Angle step change of output voltage phasor
• Scaling: 65535 ≡ 1 revolution
bSpeedCtrlIOn
C00833/31 | BOOL
Directly set the I-component of speed controller
• In order to statically specify a minimum torque, e.g. when a load is being lifted.
TRUE Se the I-component of the speed controller to the value
nSpeedCtrlI_a.
