Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 333
6 I/O terminals
6.1 Digital input terminals
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Short overview of parameters for the counting inputs:
Parameters Info Lenze setting
Value Unit
Counting input DI1
C00115/1
Fct. DI 1/2 200kHz 0: DI1(6)=In / DI2(7)=In
C00621/3
LS_DigitalInput: bCountIn1_Reset 0: Not connected
C00621/4
LS_DigitalInput: bCountIn1_LoadStartValue 0: Not connected
C02840/1
CountIn1: Starting value 0 incr
C02840/2
CountIn1: Comparison value 65535 incr
C02841/1 CountIn1: Counter content - incr
C00443/1 DIx: Terminal level -
Counting input DI6
C00115/2
Fct. DI 6/7 10kHz 0: DI1(6)=In / DI2(7)=In
C00621/97
LS_DigitalInput: bCountIn6_Reset 0: Not connected
C00621/98
LS_DigitalInput: bCountIn6_LoadStartValue 0: Not connected
C02840/3
CountIn6: Starting value 0 incr
C02840/4
CountIn6: Comparison value 65535 incr
C02841/2 CountIn6: Counter content - incr
C00443/1 DIx: Terminal level -
Greyed out = display parameter
