Lenze 8400 - Page 345

Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 345
6 I/O terminals
6.2 Digital output terminals
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Short overview of parameters for the digital output terminals:
Related topics:
Configuring exception handling of the output terminals
( 364)
User-defined terminal assignment
( 365)
Parameters Info Lenze setting
Value Unit
Digital outputs DO1 ... DO3
C00118
DigOutX: Inversion Bit coded
C00423/3
DO1 ON delay 0.000 s
C00423/4
DO1 OFF delay 0.000 s
C00423/5
DO2 ON delay 0.000 s
C00423/6
DO2 OFF delay 0.000 s
C00423/7
DO3 ON delay 0.000 s
C00423/8
DO3 OFF delay 0.000 s
C00444/1 DOx: Input level -
C00444/2 DOx: Terminal level -
High current output
C00423/9
DO "High Current" ON delay 0.000 s
C00423/10
DO "High Current" OFF delay 0.000 s
C00117 Status of brake output BD -
Relay output
C00423/1
Relay ON delay 0.000 s
C00423/2
Relay OFF delay 0.000 s
Digital outputs - terminal configuration
C00621/1
LS_DigitalOutput:bRelay 1001: LA_nCtrl_bDriveFail
C00621/2
LS_DigitalOutput:bOut1 1000: LA_nCtrl_bDriveReady
C00621/99
LS_DigitalOutput: bOut2 0: Not connected
C00621/100
LS_DigitalOutput: bOut3 0: Not connected
C00621/101
LS_DigitalOutput: bOut HighCurrent 0: Not connected
Greyed out = display parameter
