7 Technology applications
7.4 TA "Table positioning"
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Outputs
bGPLogicIn1
bGPLogicIn2
bGPLogicIn3
BOOL
Binary logic: Input signals
• The logic operation is selected in C00820
.
• The result is output at output bGPLogicOut.
nGPCompareIn1_a
nGPCompareIn2_a
INT
Analog comparison: Input signals
• The comparison operation is selected in C00680
.
• Hysteresis and window size can be set in C00680
and C00682.
• If the comparison statement is true, the output bGPCompareOut will be set to
TRUE.
bGPDFlipFlop_InD
bGPDFlipFlop_InClk
bGPDFlipFlop_InClr
BOOL
D-FlipFlop: Input signals
• Data, clock and reset input
bGPCounter1ClkUp
BOOL
Counter: Clock input
• With each edge, the module counts up by "1".
• Only FALSE-TRUE edges are evaluated.
Note: The static state "1" is not permissible at this input.
bGPCounter1ClkDown
BOOL
Counter: Clock input
• With each edge, the module counts down by "1".
• Only FALSE-TRUE edges are evaluated.
Note: The static state "1" is not permissible at this input.
bGPCounter1Load
BOOL
Counter: Loading input
• The input has the highest priority.
TRUE Accept the starting value wGPCounter1LdVal.
wGPCounter1LdVal
WORD
Counter: Starting value
• Assigned value is internally interpreted as "INT" data type (-32767 ... +32767), i.e.
the most significant bit determines the sign.
wGPCounter1CmpVal
WORD
Counter: Comparison value
• Assigned value is internally interpreted as "INT" data type (-32767 ... +32767), i.e.
the most significant bit determines the sign.
Free inputs
The following inputs can freely be interconnected on the application level.
The signals can be transferred from the I/O level to the application level via these inputs.
bFreeIn1 ... bFreeIn8
BOOL
Free inputs for digital signals
wFreeIn1 ... wFreeIn4
WORD
Free inputs for 16-bit signals
dnFreeIn1_p ... dnFreeIn2_p
DINT
Free inputs for 32-bit signals
Designator
Data type
Value/meaning
wDriveControlStatus
WORD
Status word of the inverter
• The status word contains information on the currents status of the inverter.
• See the "wDeviceStatusWord status word
" subchapter of the chapter on device
control for a detailed description of the bit assignment.
wStateDetermFailNoLow
WORD
Display of the status determining error (LOW word)
wStateDetermFailNoHigh
WORD
Display of the status determining error (HIGH word)
bDriveFail
BOOL
TRUE Inverter in error status.
•"Fault
" device status is active.
Designator
Data type
Information/possible settings
