Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 673
9 Diagnostics & error management
9.9 Error messages of the operating system
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
dF52: BuCcr error [xx.0145.00052]
Ck01: Pos. HW limit switch [xx.0184.00001]
Ck02: Neg. HW limit switch [xx.0184.00002]
Ck15: Error status sign. brake [xx.0184.00005]
Ck03: Pos. SW limit position [xx.0184.00007]
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
Device error Mains switching
• Please contact Lenze if the problem occurs again.
Response (Lenze setting printed in bold) Setting: C00595/1 ( Adjustable response)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
MCK: The hardware limit switch in positive traversing
direction has tripped.
•The bLimitSwitchPos input for travel range
monitoring via positive hardware limit switch has
been set to FALSE (fail-safe).
Reset error message and retract limit switch.
Response (Lenze setting printed in bold) Setting: C00595/2 ( Adjustable response)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
MCK: The hardware limit switch in negative traversing
direction has tripped.
•The bLimitSwitchNeg input for travel range
monitoring via negative hardware limit switch has
been set to FALSE (fail-safe).
Reset error message and retract limit switch.
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
MCK: The status monitoring of the holding brake control
has tripped.
• Check configuration of the bMBrakeApplied input for
status detection of the brake (via a switching contact
at the brake).
• Check wiring/function of the switching contact.
• Adapt waiting time (C02589/3
).
• Deactivate status monitoring (via bit 5 in C02582
).
Response (Lenze setting printed in bold) Setting: C00595/3 ( Adjustable response)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
MCK: The device has detected that the position is outside
the positive software limit position (C01229/1
).
• Increase permissible traversing range (change setting
of the software limit positions).
• Deactivate software limit position monitoring.
