Ck04: Neg. SW limit position [xx.0184.00008]
Ck17: direction conflict Ccw [xx.0184.00009]
Ck18: direction conflict Cw [xx.0184.00010]
Ck14: Target position outside SW limit position [xx.0184.00015]
Ck16: Time overflow manual operation [xx.0184.00064]
Response (Lenze setting printed in bold) Setting: C00595/4 ( Adjustable response)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
MCK: The device has detected that the position is outside
the negative software limit position (C01229/2
).
• Increase permissible traversing range (change setting
of the software limit positions).
• Deactivate software limit position monitoring.
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
Positioning profile is started in positioning mode 5 or 12
(absolute (Ccw) or absolute (Ccw) to TP); however, the
Cw rotating direction is defined by the profile
generation.
Start positioning with zero speed.
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
Positioning profile is started in positioning mode 4 or 11
(absolute (Ccw) or absolute (Ccw) to TP); however, the
Ccw rotating direction is defined by the profile
generation.
Start positioning with zero speed.
Response (Lenze setting printed in bold) Setting: C00595/14 ( Adjustable response)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
MCK: It has been attempted to position a target outside
the software limit positions (C01229/1
and C01229/2).
• Select a target within the software limit positions.
• Increase permissible traversing range (change setting
of the software limit positions).
• Deactivate software limit position monitoring.
Response (Lenze setting printed in bold)
 0: No Reaction  1: Fault  2: Trouble  3: TroubleQuickStop  4: WarningLocked  5: Warning  6: Information
Cause Remedy
PC manual control: The connection monitoring has
tripped.
• The online connection between the PC and the
inverter has been interrupted for a longer period of
time than the timeout set in C00464/1
.
• Check communication link between PC and inverter.
• Check voltage supply/function of the inverter.
• Adjust the timeout (C00464/1
).
