Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 1075
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C01228
C01229
C01230
Parameter | Name:
C01228 | MCK: Ref. sequence profile
Data type: UNSIGNED_8
Index: 23347
d
= 5B33
h
Number of the sequence profile the absolute position of which will be approached after homing.
Homing
Setting range (min. value | unit | max. value) Lenze setting
0150
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C01229 | MCK: Position limiting values
Data type: INTEGER_32
Index: 23346
d
= 5B32
h
Software limit position for limiting the valid traversing range
• The error response to leaving the valid traversing range can be parameterised in C00595/3
and C00595/4.
Note:
For limiting the traversing range by means of software limit positions, the home position must be known and the
positive software limit position must be higher than the negative software limit position!
Limit position monitoring
Setting range (min. value | unit | max. value)
-214748.3647 units 214748.3647
Subcodes Lenze setting Info
C01229/1 0.0000 units MCK: Positive SW limit position
(positive travel range limit)
C01229/2 0.0000 units MCK: Negative SW limit position
(negative travel range limit)
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C01230 | Manual jog: Setting
Data type: UNSIGNED_8
Index: 23345
d
= 5B31
h
Settings for "Manual jog" mode
Manual jog
Setting range (min. hex value | max. hex value) Lenze setting
0x00 0xFF 0x00 (decimal: 0)
Value is bit-coded: ( =bit set) Info
Bit 0  Breakpoints 1..4 on 1 ≡ approach of the parameterised breakpoint in manual
jog direction
Bit 1  Time-based start of 2nd speed 1 ≡ Automatic change-over to second manual speed
after the wating time set in C01235/1
.
Bit 2  HW limit switch on 1 ≡ Travel range monitoring via hardware limit switch is
active. The error response can be parameterised in
C00595/1
and C00595/2.
Bit 3  SW limit switch on 1 ≡ Travel range monitoring via parameterised software
limit positions is active. The error response can be
parameterised in C00595/3
and C00595/4.
