Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 825
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00053
C00054
C00055
C00056
Parameter | Name:
C00053 | DC-bus voltage
Data type: UNSIGNED_16
Index: 24522
d
= 5FCA
h
Display of the current DC-bus voltage
Display range (min. value | unit | max. value)
0 V 1000
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00054 | Motor current
Data type: UNSIGNED_16
Index: 24521
d
= 5FC9
h
Display of the current motor current/output current of the inverter
Display range (min. value | unit | max. value)
0.00 A 300.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00055 | Actual values
Data type: INTEGER_16
Index: 24520
d
= 5FC8
h
From version 10.00.00
Note:
When a single-track feedback has been selected for the HTL encoder (C00115
= 1 or 3), the sign of the actual speed
value is created from the sign of the speed setpoint. In C00055/1 und C00055/2, a positive speed is always
displayed.
Display range (min. value | unit | max. value)
-32767 rpm 32767
Subcodes Info
C00055/1 Actual value - HTL encoder FreqIn12
C00055/2 Actual value - HTL encoder FreqIn67
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00056 | Torque
Data type: INTEGER_32
Index: 24519
d
= 5FC7
h
Display of the current torque
Display range (min. value | unit | max. value)
-65000.00 Nm 65000.00
Subcodes Info
C00056/1 Torque demand
• Only in case of sensorless vector control (SLVC
) and
servo control (SC
).
C00056/2 Actual torque value
• Estimated actual torque for all motor control modes.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
