Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 863
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00226
C00227
C00228
C00231
Parameter | Name:
C00226 | L_PCTRL_1: MinLimit
Data type: INTEGER_16
Index: 24349
d
= 5F1D
h
The L_PCTRL_1 FB: Minimum output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
-199.99 % 199.99 -199.99 %
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
Parameter | Name:
C00227 | L_PCTRL_1: Acceleration time
Data type: UNSIGNED_32
Index: 24348
d
= 5F1C
h
The L_PCTRL_1 FB: Acceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.999 0.010 s
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C00228 | L_PCTRL_1: Deceleration time
Data type: UNSIGNED_32
Index: 24347
d
= 5F1B
h
The L_PCTRL_1 FB: Deceleration time for the output value of the PID process controller
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.999 0.010 s
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 1000
Parameter | Name:
C00231 | L_PCTRL_1: Operating range
Data type: INTEGER_16
Index: 24344
d
= 5F18
h
The L_PCTRL_1 FB: Operating range for the PID process controller
Setting range (min. value | unit | max. value)
0.00 % 199.99
Subcodes Lenze setting Info
C00231/1 199.99 % L_PCTRL_1
: Pos. maximum
C00231/2 0.00 % L_PCTRL_1: Pos. minimum
C00231/3 0.00 % L_PCTRL_1
: Neg. minimum
C00231/4 199.99 % L_PCTRL_1
: Neg. maximum
Read access Write access CINH PLC STOP No transfer COM MOT Scaling factor: 100
