15 Parameter reference
15.2 Parameter list
864
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00233
C00234
C00235
C00236
C00241
Parameter | Name:
C00233 | L_PCTRL_1: Root function
Data type: UNSIGNED_8
Index: 24342
d
= 5F16
h
The L_PCTRL_1 FB: Use of the root function at the actual value input
Selection list (Lenze setting printed in bold) Info
0Off Root function inactive
• The actual value nAct_a remains unchanged for
further processing
1 On Root function active
• The root is extracted of the actual value nAct_a for
further processing
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00234 | Oscillation damping influence
Data type: UNSIGNED_16
Index: 24341
d
= 5F15
h
Oscillation damping
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 250.00 5.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00235 | Oscillation damping filter time
Data type: UNSIGNED_8
Index: 24340
d
= 5F14
h
Oscillation damping
Setting range (min. value | unit | max. value) Lenze setting
2 ms 250 32 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00236 | Field weakening oscillation damping
Data type: UNSIGNED_8
Index: 24339
d
= 5F13
h
Oscillation damping for idling machines
Oscillation damping
Setting range (min. value | unit | max. value) Lenze setting
04014
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00241 | L_NSet_1: Hyst. NSet reached
Data type: INTEGER_16
Index: 24334
d
= 5F0E
h
The L_NSet_1 FB: Hysteresis window for the zero detection of the speed output setpoint
• The speed threshold for the zero detection is 1 %
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 0.50 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
