Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 865
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00242
C00243
C00244
C00245
Parameter | Name:
C00242 | L_PCTRL_1: Operating mode
Data type: UNSIGNED_8
Index: 24333
d
= 5F0D
h
The L_PCTRL_1 FB: Selection of the operating mode
• Depending on the selection, the blue switches in the displayed signal flow are set accordingly in the Engineer on
the Application parameters tab for the L_PCTRL_1
FB.
Selection list (Lenze setting printed in bold) Info
0Off The input setpoint nNSet_a is output without any
changes at the output nOut_a.
1nNSet + nNSet_PID nNSet_a and nAct_a are used as PID input values. The
arriving nNSet_a is additively linked to the value output
by the PID element.
2nSet_PID nSet_a and nAct_a are used as PID input values. The
input nNSet_a is not considered.
3nNSet_PID nNSet_a and nAct_a are used as PID input values. The
input nSet_a is not considered.
4 nNSet + nSet_PID nSet_a and nAct_a are used as PID input values. The
arriving nNSet_a setpoint is additively linked to the value
output by the PID element.
5 nNSet || nSet_PID nSet_a and nAct_a are used as PID input values. The
setpoint nNSet_a is output at the output nOut_a . The
PID output value is output at the output nPIDOut_a.
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00243 | L_PCTRL_1: Acceleration time influence
Data type: UNSIGNED_32
Index: 24332
d
= 5F0C
h
The L_PCTRL_1 FB: Acceleration time for showing the PID output value
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.999 5.000 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00244 | L_PCTRL_1: Deceleration time influence
Data type: UNSIGNED_32
Index: 24331
d
= 5F0B
h
The L_PCTRL_1 FB: Deceleration time for masking out the PID output value
Setting range (min. value | unit | max. value) Lenze setting
0.000 s 999.999 5.000 s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1000
Parameter | Name:
C00245 | L_PCTRL_1: PID output value
Data type: INTEGER_16
Index: 24330
d
= 5F0A
h
The L_PCTRL_1 FB: Display of the output value of the PID process controller
Display range (min. value | unit | max. value)
-199.99 % 199.99
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
