Lenze 8400 - Page 866

15 Parameter reference
15.2 Parameter list
866
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00246
C00247
C00249
C00250
C00251
Parameter | Name:
C00246 | L_PCTRL_1: nAct_a internal
Data type: INTEGER_16
Index: 24329
d
= 5F09
h
From version 04.00.00
FB L_PCTRL_1
: Display of the internal actual value
Display range (min. value | unit | max. value)
-199.99 % 199.99
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00247 | L_PCTRL_1: Window setpoint reached
Data type: INTEGER_16
Index: 24328
d
= 5F08
h
From version 06.00.00
FB L_PCTRL_1
: Window for comparison operation "actual value = setpoint"
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 2.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00249 | L_PT1_1: Time constant
Data type: UNSIGNED_16
Index: 24326
d
= 5F06
h
FB L_PT1_1: Time constant Tn
Setting range (min. value | unit | max. value) Lenze setting
0 ms 5000 2000 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00250 | L_PT1 2-3: Time constant
Data type: INTEGER_16
Index: 24325
d
= 5F05
h
Setting range (min. value | unit | max. value)
0 ms 5000
Subcodes Lenze setting Info
C00250/1 2000 ms L_PT1_2
: Time constant
C00250/2 2000 ms L_PT1_3
: Time constant
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00251 | L_DT1_1: Time constant
Data type: INTEGER_16
Index: 24324
d
= 5F04
h
FB L_DT1_1: Time constant Tn
Setting range (min. value | unit | max. value) Lenze setting
10 ms 5000 1000 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
