Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 867
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00252
C00253
C00254
C00265
C00270
Parameter | Name:
C00252 | L_DT1_1: Gain
Data type: INTEGER_16
Index: 24323
d
= 5F03
h
FB L_DT1_1: Gain factor Vp
Setting range (min. value | unit | max. value) Lenze setting
-320.00 320.00 1.00
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00253 | L_DT1_1: Sensitivity
Data type: UNSIGNED_8
Index: 24322
d
= 5F02
h
FB L_DT1_1: Selection of sensitivity
• Depending on the selection, the number of indicated higher-order bits is evaluated.
Note:
The most significant bit determines the sign of the value, the remaining bits determine the numerical value.
Selection list (Lenze setting printed in bold) Info
1 15 bits Bit 0 ... bit 14 are evaluated
2 14 bits Bit 0 ... bit 13 are evaluated
3 13 bits Bit 0 ... bit 12 are evaluated
4 12 bits Bit 0 ... bit 11 are evaluated
5 11 Bit Bit 0 ... bit 10 are evaluated
6 10 Bit Bit 0 ... bit 9 are evaluated
7 9 Bit Bit 0 ... bit 8 are evaluated
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00254 | Kp position controller
Data type: UNSIGNED_16
Index: 24321
d
= 5F01
h
Gain for following error compensation
Setting range (min. value | unit | max. value) Lenze setting
0.00 1/s 500.00 5.00 1/s
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
Parameter | Name:
C00265 | SLVC: Filtering of setpoint and actual currents
Data type: UNSIGNED_8
Index: 24310
d
= 5EF6
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00270 | SC: Freq. current setpoint filter
Data type: UNSIGNED_16
Index: 24305
d
= 5EF1
h
Frequency to be inhibited by the current setpoint filter at servo control (SC) and sensorless control for synchronous
motors (SLPSM
).
Setting range (min. value | unit | max. value) Lenze setting
40.0 Hz 1000.0 200.0 Hz
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10
