Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23 927
15 Parameter reference
15.2 Parameter list
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00597
C00598
C00599
Parameter | Name:
C00597 | Resp. to motor phase failure
Data type: UNSIGNED_8
Index: 23978
d
= 5DAA
h
Response to motor phase failure
• If a phase current does not exceed the threshold set in C00599
for more than one period, the response set here
will be triggered.
Selection list (Lenze setting printed in bold)
0No Reaction
1Fault
5 Warning
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00598 | Resp. to open circuit AINx
Data type: UNSIGNED_8
Index: 23977
d
= 5DA9
h
Configuration of monitoring of the analog inputs
Analog terminals
Selection list
0 No Reaction
1Fault
2Trouble
3 TroubleQuickStop
5 Warning
Subcodes Lenze setting Info
C00598/1 3: TroubleQuickStop Response to open circuit at AIN1 if configured as
4 ... 20 mA current loop
C00598/2 3: TroubleQuickStop Response to open circuit at AIN2 when being configured
as 4 ... 20 mA-current loop
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00599 | Motor phase failure threshold
Data type: INTEGER_16
Index: 23976
d
= 5DA8
h
Threshold for motor phase failure monitoring
•100% ≡ rated inverter current (C00098
)
• If a phase current does not exceed the threshold set here for more than one period, the response to motor phase
failure set in C00597
will be triggered.
Setting range (min. value | unit | max. value) Lenze setting
0.00 % 100.00 5.00 %
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 100
