15 Parameter reference
15.2 Parameter list
948
Lenze · 8400 HighLine · Reference manual · DMS 12.0 EN · 06/2017 · TD23
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00670
C00671
C00672
C00673
C00674
Parameter | Name:
C00670 | L_OffsetGainP_1: Gain
Data type: INTEGER_32
Index: 23905
d
= 5D61
h
The L_OffsetGainP_1 FB: Gain as multiplier of the input signal + offset
Setting range (min. value | unit | max. value) Lenze setting
-100.0000 100.0000 1.0000
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C00671 | L_OffsetGainP_2: Gain
Data type: INTEGER_32
Index: 23904
d
= 5D60
h
The L_OffsetGainP_2 FB: Gain as multiplier of the input signal + offset
Setting range (min. value | unit | max. value) Lenze setting
-100.0000 100.0000 1.0000
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C00672 | L_OffsetGainP_3: Gain
Data type: INTEGER_32
Index: 23903
d
= 5D5F
h
The L_OffsetGainP_3 FB: Gain as multiplier of the input signal + offset
Setting range (min. value | unit | max. value) Lenze setting
-100.0000 100.0000 1.0000
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 10000
Parameter | Name:
C00673 | L_OffsetGainPhiP 1-2: Offset
Data type: INTEGER_32
Index: 23902
d
= 5D5E
h
Angular offset (is added to the angular input signal)
Setting range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
Subcodes Lenze setting Info
C00673/1 0 incr. L_OffsetGainPhiP_1
: Offset
C00673/2 0 incr. L_OffsetGainPhiP_2: Offset
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00674 | L_OffsetGainPhiP 1-2: Gain
Data type: INTEGER_32
Index: 23901
d
= 5D5D
h
Angular gain as multiplier of the input signal + angular offset
Setting range (min. value | unit | max. value)
-2147483647 2147483647
Subcodes Lenze setting Info
C00674/1 65536 L_OffsetGainPhiP_1
: Gain
C00674/2 65536 L_OffsetGainPhiP_2
: Gain
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
