Action Yes No
Step 5
Reseat all the connectors on the controller PCBA, then POR the machine.
Does the error remain?
Replace the controller
PCBA. See “Mailbox
controller PCBA
removal” on page
707.
If the error persists,
then replace the
mailbox. See “Mailbox
option removal” on
page 688.
The problem is solved.
Finisher side door error service check
Action Yes No
Step 1
Is the staple finisher the only output option installed?
Go to step 4. Go to step 2.
Step 2
Remove all output options and re-install only the staple finisher.
Enter Diagnostics Menu and navigate to:
Output bin tests > Feed to all bins
Does the output option feed to all bins normally?
The problem may not
be on this option tray.
Reinstall the
remaining output
options one at a time
and test each option
for errors. Proceed
with the appropriate
service check based on
the error message and
the output option
being tested.
Go to step 3.
Step 3
Check the auto connector end of the option previously installed below the
staple finisher.
Is it free of damage?
Go to step 4. Replace the upper
interface cable of the
output option
previously installed
under the staple
finisher.
Step 4
Check the lower interface cable. If damaged, then replace the lower
interface cable. Go to Stapler lower interface cable removal” on
page 661.
Remove the left cover. Reseat the cable (J15) on the controller PCBA, then
POR the machine.
Does the error remain?
Go to step 5. The problem is solved.
Step 5
Check if the stapler cartridge access door closes properly. Make sure that
obstructions are cleared and that the access door is correctly installed.
Is the above component functioning properly?
Go to step 6. Replace the stapler
cartridge access door.
Go to “Stapler
cartridge access door
removal” on page
632.
4063
Diagnostic information
298
