Action Yes No
Step 5
Open the left cover, reseat all connectors on the controller PCBA. POR the
machine and perform a Print test.
Does the error remain?
Replace the controller
PCBA. Go to “Output
expander controller
PCBA removal” on
page 562.
If the error persists,
then replace the
output expander. Go to
“Output expander
option removal” on
page 554.
The problem is solved.
Output expander rear door undetected service check
Action Yes No
Step 1
Is the output expander the only output option installed?
Go to step 4. Go to step 2.
Step 2
Check the lower interface cable. If damaged, then replace the lower
interface cable. See Lower interface cable removal” on page 563.
Reseat the cable J1 on the controller PCBA, then POR the machine.
Does the error remain?
Go to step 3. The problem is solved.
Step 3
Check the auto connector end of the option below the expander.
Is it free of damage?
Go to step 4. Replace the upper
interface cable of the
output option under
the expander.
Step 4
Remove all output options and re-install only the expander. Enter
Diagnostics Menu and navigate to:
OUTPUT BIN TESTS >Feed Tests >Output Bin 1
Select Single.
Does the output option feed normally?
The problem may not
be on this option tray.
Reinstall the
remaining output
options one at a time
and test each option
for errors. Proceed
with the appropriate
service check based on
the error message and
the output option
being tested.
Go to step 5.
4063
Diagnostic information
314
