Mailbox upper interface cable removal
1 Remove the mailbox top cover. See “Mailbox top cover removal” on page 688,
2 Remove the mailbox left cover. See “Mailbox left cover removal” on page 696.
3 Disconnect the upper interface cable J1B from the controller PCBA.
4 Crimp both connector pins, using pliers to make them fit the pin holes. Push the connector off its slot.
5 Remove the upper interface cable.
Mailbox diverter motor removal
1 Remove the mailbox top cover. See “Mailbox top cover removal” on page 688.
2 Remove the mailbox left cover. See “Mailbox left cover removal” on page 696.
3 Disconnect the cable (A) from the divert motor.
4063
Repair information
712
