Action Yes No
Step 4
Check the lower interface cable. If damaged, then replace the lower
interface cable. Go to “Stapler lower interface cable removal” on
page 661.
Remove the left cover. Reseat the cable (J15) on the controller PCBA, then
POR the machine.
Does the error remain?
Go to step 5. The problem is solved.
Step 5
Open the left cover. Reseat the cables (J18 and J15) on the controller PCBA,
then POR the machine.
Does the error remain?
Go to step 6. The problem is solved.
Step 6
Open the left cover, reseat all connectors on the controller PCBA and then
POR the machine.
Does the error remain?
Replace the controller
PCBA. Go to “Staple
finisher option
removal” on page
621.
If the error persists,
then replace the staple
finisher. Go to “Staple
finisher option
removal” on page
621.
The problem is solved.
Finisher bin error service check
Action Yes No
Step 1
Is the staple finisher the only output option installed?
Go to step 4. Go to step 2.
Step 2
Remove all output options and re-install only the staple finisher.
Enter Diagnostics Menu and navigate to:
Output bin tests > Feed to all bins
Does the output option feed to all bins normally?
Perform step 2 again
using the other
remaining output bins.
Go to step 3.
Step 3
Check the auto connector end of the option previously installed below the
staple finisher.
Is it free of damage?
Go to step 4. Replace the upper
interface cable of the
output option
previously installed
under the staple
finisher.
4063
Diagnostic information
302
