Assembly 5: Drive motors
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7684 1 1 Duplex motor with cable See “Duplex motor
removal” on
page 457.
2 40X7695 1 1 Duplex cooling fan See “Duplex cooling
fan removal” on
page 508.
3 40X7580 1 1 Cartridge cooling fan See “Cartridge
cooling fan
removal” on
page 507.
4 40X7596 1 1 Toner add motor with cable See “Toner add
motor removal” on
page 503.
5 40X7576 1 1 Fuser drive motor cable See “Fuser drive
motor removal” on
page 494.
6 40X7595 1 1 Fuser drive motor (belt fuser printers only) See “Fuser drive
motor removal” on
page 494.
6 40X8401 1 1 Fuser drive motor (hot roll fuser printers only) See “Fuser drive
motor removal” on
page 494.
7 40X7594 1 1 Main drive motor See “Main drive
motor removal” on
page 497.
8 40X7574 1 1 Main motor cable See “Main cooling
fan removal” on
page 496.
9 40X7579 1 1 Main cooling fan with cable See “Main cooling
fan removal” on
page 496.
10 40X7682 1 1 Upper redrive motor with cable See “Upper redrive
motor removal” on
page 469.
11 40X8483 1 1 Fuser cooling fan (hot roll fuser printers only) N/A
12 40X8484 1 1 Fuser cooling fan cable (hot roll fuser printers only) N/A
4063
Parts catalog
816
