Assembly 7: Frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8316 1 1 Right control panel hinge, with control panel
cable
See “Right control panel
hinge removal” on
page 450.
2 40X7732 1 1 Left frame pivot See “Left frame pivot
removal” on page 462.
3 40X7733 1 1 Right frame pivot See “Right frame pivot
removal” on page 464.
4 40X7714 2 1 Imaging unit clamp N/A
5 40X7589 4 1 Fastener plate N/A
6 40X7728 1 1 Right frame extension with tray latch
(integrated 550‑sheet tray)
See “Right frame
extension” on page 483.
6 40X8408 1 1 Right frame extension (integrated 250‑sheet
tray)
See “Right frame
extension” on page 483.
7 40X7590 4 1 M5x12 screw N/A
8 40X7727 1 1 Left frame extension (integrated 550‑sheet
tray)
• with media size sensor with cable
• with input option interface cable
• with sensor (media tray position) with
cable
See “Left frame extension
removal” on page 477.
8 40X8407 1 1 Left frame extension (integrated 250‑sheet
tray)
• with media size sensor with cable
• with input option interface cable
• with sensor (media tray position) with
cable
See “Left frame extension
removal” on page 477.
9 40X7716 2 1 Toner cartridge lock N/A
10 40X7721 1 1 Torsion spring N/A
11 40X7719 1 1 Torsion spring N/A
12 40X7717 2 1 Toner cartridge clamp N/A
13 40X7720 1 1 Torsion spring N/A
14 40X7718 1 1 Torsion spring N/A
15 40X8315 1 1 Left control panel hinge See “Left control panel
hinge removal” on
page 447.
16 40X7724 2 1 Recoil spring N/A
17 40X7575 1 1 Top option interface cable N/A
