Assembly 12: 550-sheet tray option
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8160 1 1 550-sheet tray option upper interface cable “Drawer upper interface
cable removal” on page
520
2 40X7593 1 1 Pick roller “Drawer pick roller
removal ” on page 516
3 40X7592 1 1 Sensor (pick roller position) “Sensor (pick roll position)
removal ” on page 516
4 40X8158 1 1 Sensor (pick) “Sensor (pick) removal” on
page 525
5 40X8156 1 1 Sensor (pass through) “Sensor (drawer pass
through) removal ” on
page 527
6 40X8159 1 1 550-sheet tray option lower interface cable “Drawer lower interface
cable removal” on page
521
7 40X7713 1 1 Separation roller “Media tray separation
roller removal” on page
514
8 40X8109 1 1 550-sheet tray front cover “Media tray front cover
removal” on page 515
9 40X8541 4 1 Media size actuator “Media size actuator
removal” on page 480
10 40X7742 1 1 550-sheet tray “Media tray assembly
removal” on page 515
11 40X8157 1 1 550-sheet tray option transport motor “Drawer transport motor
removal” on page 524
12 40X7591 1 1 Media feeder “Drawer media feeder
removal ” on page 522
13 40X8155 1 1 550-sheet tray option controller PCBA “Drawer controller PCBA
removal” on page 519
