Assembly 20: High capacity output expander option 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8202 1 1 HCOE left cover “HCOE left cover removal” on
page 589
2 40X8730 1 1 HCOE main motor “HCOE main motor removal” on
page 607
3 40X8206 1 1 HCOE upper interface cable “HCOE upper interface cable
removal” on page 594
4 40X8199 1 1 HCOE controller PCBA “HCOE controller PCBA removal” on
page 591
5 40X8205 1 1 HCOE lower interface cable “HCOE lower interface cable
removal” on page 593
6 40X8721 2 2 HCOE option latch “HCOE option latch removal” on
page 594
7 40X8256 1 1 HCOE diverter motor “HCOE diverter motor removal” on
page 595
8 40X8731 2 2 HCOE Tray pinion “HCOE tray pinion removal” on
page 598
9 40X8733 2 2 HCOE Tray spring “HCOE tray spring removal” on
page 597
10 40X7592 2 1 Sensor (HCOE rear door interlock) “Sensor (HCOE rear door interlock)
removal” on page 599
11 40X8728 1 1 Sensor (HCOE tray HP) “Sensor (HCOE tray HP) removal” on
page 596
12 40X8726 1 1 HCOE main drive gear assembly “HCOE main drive gear assembly
removal” on page 605
13 40X8722 1 1 HCOE diverter plunger assembly “HCOE diverter plunger assembly
removal” on page 604
14 40X7592 2 1 Sensor (HCOE diverter HP) “Sensor (HCOE diverter HP) removal”
on page 609
